DESCRIPTION: 102-05F is an electrically conductive ink, coating and adhesive suitable for screen printing very

narrow circuit lines. This product features excellent adhesion to Kapton, Mylar, glass and a variety of other

substrates. Unlike conventional conductive materials, this product is very resistant to abrasion and scratching.

Some applications for 102-05F include, but are not limited to, emi/rfi shielding of polyimide flexible circuits, polymer

thick film circuitry, membrane switches, electrical attachments for surface mounted devices, and for bonding to

Indium Tin Oxide (ITO) sputtered surfaces. 102-05F can be further cross-linked with B187 curing agent for

applications requiring resistance to solvents and high humidity. Refer to handling instructions for additional

information.

TYPICAL CURED PROPERTIES:

Consistency  Smooth Paste

Filler  Silver

Percent Silver (cured)  85

Crease Resistance  Excellent

Volume Resistance (Ω-cm)  0.00005

Sheet Resistivity (Ω/sq./mil)  0.019

Solderable No

Solvent Resistance Excellent

Hydrolytic Stability Excellent

Useful Temperature Range (°C) -55 to 200

Thermal Stability Good to 325

Wet Coverage (in2/gm/mil) 28.0

Specific Gravity 2.52

SUGGESTED HANDLING & CURING: 102-05F is ready to use as supplied. Further thinning may be accomplished

by adding small amounts of CMI Thinner #203 and/or butyl cellosolve acetate. Prior to using, be certain to

resuspend silver. Best properties, for most applications, result when cured for 1 hour at 175°C. Good properties are

obtained on a variety of substrates by curing at temperatures ranging from 50°C to 150°C. NOTE: Add 1phr B187

catalyst when using low temperature cures. The use of B187 is suggested to impart a high degree of chemical

resistance to the conductive lines. End user is advised to experimentally determine temperature and time best

suited for individual applications.

STORAGE: Shelf life - 4 months at 25°C; or 6 months at 5°C; or 12 months at -10°C.

SAFETY & HANDLING: Use with adequate ventilation. Keep away from sparks and open flames. Avoid

prolonged contact with skin and breathing of vapors. Wash with soap and water to remove from skin.
